XQ031
XUANQING
7308900000
Hot dipped galvanized steel grating
Product description
Product Name | Steel grating |
Material | Low carbon steel / Stainless steel |
Grade | CN: Q235, Q345, USA: A36, UK: 43A |
Standard | CN: YB/T4001-1998, USA: ANSI/NAAMM, UK: BS4592-1987, AUS1657-1988, JJS |
Certification | CE, ISO9001 |
Bearing bar size | 20X5, 25X3, 25X4, 25X5, 30X3, 30X4, 30X5, 32X3, 32X5, 40X5, 50X4... 75X8, 100X8mm, etc |
Bearing bar pitch | 20,25,30,32.5,34.3,40,50,60,62,65mm |
Bearing bar type | Plain, Serrated (tooth-like), I bar (I section), Serrated-I |
Cross bar size | 5X5, 6X6, 8X8mm (twisted bar)/5, 6, 8mm ( round bar) |
Cross bar pitch | 40, 50, 60, 65, 76, 100, 101.6, 120, 130mm, etc. |
Panel size | 3x20ft,3x24ft,3x30ft,5800x1000,6096x1000,6400x1000, as request |
Surface treatment | Untreated, hot DIP galvanized, cold DIP galvanized, painted, powder coated, pickling, electrolytic polishing, or as customers’ requirement. |
Galvanization Standard | CN: GB/T13912, USA: ASTM (A123), UK: BS729 |
Color | Silver/Black |
Application | petroleum and chemical, port, power, transportation, papermaking, medicine, steel and iron, food, municipality, real estate, manufacturing |
